Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 208
Fig. 325. Probs. 176, 177 and 178. Hand Pump. PROB. 176, Fig. 325.—Make a detail working drawing of the PUMP BODY. PROB. 177, Fig. 325.—Make a working drawing showing each detail separatelyfor the iVs plunger pump, for all parts except the pump body. Use large sheet. PROB. 178, Fig. 325.—Make an… … STEAM TURBINE BEARING 204. The steam turbine bearing shown in Figs. 326, 327, and 328 is for a Type 6,B. F. Sturtevant Steam Turbine. The bearings are split to permit easy adjustment.The two halves are held together with cap screws. The spherical seating makes thebearing self-aligning. The rapidly…
