Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 60
eth are cut; hence the dimensions forhubs, diameters, etc., must be so put on that they can be conveni-ently used by the machinist in turning up the gear blank in anordinary lathe. Worm and Worm Gear. Fig. 43 shows the detail of a wormand worm gear. The teeth on the worm gear are twisted; and if… … ONE-STEEL -F.A.O. Fig. 41. Detail of Pinion to Mesh with Gear of Fig. 40 50 MACHINE DRAWING
