Fig. 64. Simple Drawing of Left- and Right-Handed Square Screw Threads etc., tangent to the two helices and the projection of the thread iscompleted. It is necessary to draw the invisible parts of the twohelices in order to draw the lines ST, XY, etc.; but they need notbe left on the finished…
