Fig. 33. Thread Representations. Fig. 34. Where a hole does not go all the way through a piece, the angle of theend of the drill leaves the end of the hole pointed, drawn with 30° linesas shown in Fig. 34. TABLE 1 Dimensions of U. S. Standard Threads Diameter Threads Diameter Root Root per Inch of…
