Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 50
o the rotor. The steam enters and leaves the rotor in a circular motionseveral times before its kinetic energy is absorbed and its velocity dropped to that ofthe rotor. It then passes out into the exhaust. 73. Detail Drawings.—A detail drawing, Fig. 74 is one which con-tains the necessary views of… … |H h ^//4? Thds. per In.
