Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 89
FiG. 145. Connecting Rod End. shape, or other form of cross section. Types of connecting rod ends areshown in Figs. 144, 145 and 146. … Connecting Rod End. 117. An eccentric is a circular disc which rotates about an axis whichdoes not pass through its center, Fig. 147. An eccentric as made for MACHINE DETAILS 79 Total up anddot^n mofion.or Travel
Machinery
