Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 98
Fig. 164. Babbitted Boxes. brass, flows more easily under pressure, and if heated will melt withoutseizing. Its frictional resistance is low so that it makes a good material … ---Length = /iDI^ Fig. 165. Solid Bearing. to use. It is too weak to support a load so it has to be held in place byshells of brass or cast iron which are provided with anchorage grooves.The babbitt may be melted and poured into the shell, using the shaftto mould it to the right size. For better…
