Dingey, Peter Spear. [from old catalog] · New York, J. Wiley & sons · leaf 105
14, i:placed in the bottom of the mould; this flange is mad(in segments and is for bolting the brake wheel to th^drum. After the inside is rammed up and lifted oulthis flange, E, and the lagging are drawn in and thgroove finished off and the skin dried. Some may say that a pattern such as I have… … PATTERN MAKING. 61 MAKING SHEAVES FROM CORE-BOXES. I PROPOSE to give under this head some ideas formaking sheaves of various kinds, and will first give theway for making large ones from core-boxes. The style of sheaves, shown with cast arms, is thatwhich is used to transmit power on cable car…
Patternmaking
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
