Dingey, Peter Spear. [from old catalog] · New York, J. Wiley & sons · leaf 44
he prints. The flanges aremade thick enough to turn the fillet on the back of them.They should be got out, as shown in Fig. 35 ; this willprevent the shrinkage of the wood from affecting theflanges to any great extent. When the body of the cylinder is built up and turned,the steam chest is made and… … Fig. 38. Fiff. 30. ^f Fig. 37.
Patternmaking
