Machinery and processes of the industrial arts, and apparatus of the exact sciences (1869)
Barnard, Frederick A. P. (Frederick Augustus Porter), 1809-1889 · Washington, Govt. print. off. · leaf 122
ffing-box s, at the end of D7.There are also stuffing boxes at t and V. Fig. 27 is a view of the engine in plan, andFig. 28 is a section through G H, in which therelation of the induction and eduction pipesto the external and intermediate cylinders is clearly shown. coques water-engine. A third… … 106 PARIS UNIVERSAL EXPOSITION. shaft instead of an eccentric, in consequence of which arrangement thechange is made abruptly at the end of the stroke; and in the admissionof a small amount of air along with the water, by means of which thedanger of a hydraulic concussion is obviated. This last…
Machinery · Scientific apparatus and instruments
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
