Scbieles Turbine—plan. Fisf. 34. … The floats have such a form as may allowthe water to expend its force in giving ro-tary motion to the wheel, and finally toescape in a direction up or down nearlyparallel to the axis.t The figures represent the Schiele turbineI as placed in the ordinary position with theaxis vertical. But it works…
