same volume of liquid shall pass through every concentric cylindric sec-tion in the same time, and that the radial velocity shall be constant. The general external appearance of the pump is shown in Fig. 45,where the form of the enclosing box is seen to correspond generally tothe condition just… … Gwynne & Co.s Centrifugal Pump—section through the axis—scale, 1-12. the manner in which the water is admitted. H is the pipe through whichthe water arrives from this source; H and H are sections of the twochannels by which it is led to K and K, the central openings by which it 180 PARIS…
