on has ten teeth, and thebevel wheel which it actuatesforty-two teeth. The pinion onthe vertical axis of this wheelhas again ten teeth, and theinternal gearing sixty-fiveteeth. The 1 ength of the crankis one-third of a metre, the di-ameter of the screw one deci-metre, (four inches,) andthe distance… … Chollet-Champions Mechanical Press. the crank on the axis of the vertical wheel E, which, by the Fig. 66.
