t of intersectionis the center of the circle. To draw any number ofcircles between two inclinedlines touching themselves andthe lines. (See Fig. 18).Solution: Draw center line ef. Drawfirst circle on line i g. Frompoint of intersection betweenthis circle and the center line draw the line h,… … Fig.
