aced at90° to the pitch line ; in the table find the number correspond-ing to the pitch required, and describe the curve for the face,and then move one pitch to the left, and describe the flankas already explained. Figure 5 also shows a pinion of 15 teeth in mesh with aninternal gear of 30 teeth,… … 126 THE MACHINIST AND TOOL MAKERS INSTRUCTOR.
