gent line and the vertical, while P becomesthe load resting on a single dx, or horizontal distance be-tween the middles of the two dss. That is, Fig. 336, ifj= weight of a cubic unit of theloading, P=yzdx. (The lamina ofarch and load considered is unity,| to paper, in thickness.) S0=aconstant =… … Fig. 336. yz H,. p sin3# (3) Call the radius of curvature at the crown p0, and sincethere z= z0 and 0=90°, (3) gives yz0p0=H0; hence (3) maybe written z = «o/>0 p sin3 w This is the law of vertical depth of loading required. Fora point of the linear arch where the tangent line is verti-cal, sin…
