The machinist and tool maker's instructor, containing an easy method of calculating and laying out difficult work in the machine shop .. (1896)
Genung, Edward. [from old catalog] · New York [Press of J. B. Savage, Cleveland] · leaf 190
1 s$ I vV ate THE MACHINIST AND TOOL MAKER S INSTRUCTOR. 185 … Figure 50, which is also thesame as figure 49, is shown inposition for milling a hollow millfor screw machines. After set-ting the cutter in position, asshown, the table should be swiv-eled from about 20° for a y2 millto about 30° for a iy8 mill.• For fluting reamers we some- i times use the cutter…
Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
