Manual for railroad engineers and engineering students : containing the rules and tables needed for the location, construction, and equipment of railroads as built in the United States (1883)
Vose, George L. (George Leonard), 1831-1910 · Boston : Lee and Shepard · leaf 229
Fig. 98. This is the general form of a fine steel bridge of 137 feet span.over a rapid torrent upon the Herljunga and Wernersborg Rail-way in Sweden. Fig. 99 combines the direct and the inverted … Fig. 99. bowstrings ; an arrangement illustrated by the Royal AlbertBridge, erected by Mr. Brunei over the Tamar, at Saltash, in ON THE STRAINS IN GIRDERS. 205 Cornwall. This immense structure lias spans of 445 feet ; theupper chord being composed of wrought iron cylindrical tubes,and the lower one…
Railroad engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
