An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 155 — their strength is notsufficient to stand a higher pressure.The fire passes along the bottom A,and then once more along the sidesB C, C D . . . around the whole boiler,before entering the chimney. Toprevent the bending out of the con-cave bottom and lateral surfaces, these parts of the boiler are… … Fig. 616.
