A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 158
space is enclosed by water, and the products of combustiontraverse a longer distance ABCDE before entering thechimney at F. These boilers are very economical, butthey can only be employed for low pressures on accountof their sharp corners and angles. These marine boilershave been recently much… … boiler are shown in Fig. 621, I, II. A BS is an ordinaryboiler with internal fire space A B, and CD are twelve heat- 146 HEAT, STEAM, AND STEAM ENGINES. [§403. ing tubes, through which the heated air from the chamberAis conducted back to the chimney at E. The water WK Wsurrounds all the heating…
Mechanics, Applied · Mechanical engineering
