houldered upon the exterior,and upon this shoulder rests a ring of insulating material largerthan the part of the socket it incloses, but with a flange extend- 182 THE ELECTRIC LIGHT. ing inwardly at tbe top, so as to approacli closely the upper part,a chamber being formed thereby—the socket… … Fig. 96. edges contact with and close circuit between the two pins beforenoted. Upon the socket within the ring a spring pawl is fastened,taking into recesses cut upon the interior of the ring, so as tolimit the movement of the ring upon the socket and also indi-
