A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 187

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 187 — If we suppose the sheet A B CD, Fig. 630, supported bystays a, b, c ... cut up into strips as A F and G //, parallelto the diagonals ae and bd oi the squares formed by anyfour stays, then we can directly apply the formula de-veloped in the precedmg paragraph, e = y T* to the determination of the…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
