A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 283

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 283 — it is better to make the steampipe rather wide than narrow, especiallyin machines of high pressure and greatpiston speed. The arrangement of the regulating orsteam throttle valve is shown in Fig. 697.A A \^ 2i portion of the steam pipe, B thevalve, CX\\.^ axis, Za set screw, and E Fthe lever for… … § 44C.] THE STEAM ENGINE. 271

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
