The art of weaving, by hand and by power, with an introductory account of its rise and progress in ancient and modern times (1844)
Gilroy, Clinton G · New York, Baldwin · leaf 378
sed vibration in the lever J, by meansof the connecting rod I, which by means of the dog or catch V,(Fig. 163) gathers more teeth in the ratchet wheel M, and conse-quently increases the speed of revolution of the yarn beam A, there-by compensating for the decreased diameter, as already… … 356 THE ART OF WEAVING. crank lever HH, to which the connecting rod I, is attached, will beseen a series of small holes, and it is by connecting the rod I, to anyone of these holes, either nearer or further from tiie fulcrum of thebell-crank lever H H, that the amount of vibration of the…
Weaving
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
