A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 293
m presses the valve on its seat is, of course, equal tothe difference between the cross-sections A A and B B. I 450.—Condenser.—In the non-condensing engine, thesteam, after acting in the cylinder, is discharged into theair or under water; in the condensing engine, however,it passes into the… … shown in Fig. 711. A is the discharge pipe, which con-ducts the waste steam into the reservoir B C, and D E the Fig. 712.
