The roads and railroads, vehicles, and modes of travelling, of ancient and modern countries; with accounts of bridges, tunnels, and canals, in various parts of the world .. (1839)

London : J.W. Parker · leaf 313

An illustration from The roads and railroads, vehicles, and modes of travelling, of ancient and modern countries; with accounts of bridges, tunnels, and canals, in various parts of the world .., 1839, leaf 313 — een at e, fig. 10.Below them, at f, is the ash-pit. After traversing theback of the fire-box, they arrive at the vessel b, as seen inthe side-view. The flame and smoke play round and be-tween these tubes, and vaporize very rapidly the water inthem. The steam, as it is formed, passes up into… … LOCOMOTIVE CARRIAGES. 30] In Hancocks toilers the water is contained betweena number of upright plates of iron, as in the followinglateral view. The water is thus distributed into thin Fig. 11

Roads · Railroads · Bridges · Vehicles

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
