A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 303
= ± 135°. Finally, Fig. 725 represents an engine with two in-clined cylinders. The connection of the piston rodsD E, D, E^ with the cranks M K M K^ is exactly the sameas in the engine in Fig. 719. The angle K MK^ betweenthe cranks is equal to the angle D MD^ between the twopiston rods minus 90°. If… … A horizontal maiine engine with two long piston rodsA B, A^B/\s shown in Fig. 726. To economize space, the
Mechanics, Applied · Mechanical engineering
