in of no sensible diameter, from which the meridian section may be constructed, and from it theoutline of a working tooth derived in the usual manner by assigning any diameter at pleasure to thecylindrical pin. This arrangement may also be modified as in Fig. 2148, the cylindrical pins being fixed… … 36 GEARING, FRICTIONAL. cither modification the cylindrical pins may be assigned to the conical wheel and teeth constructedfor the other. And finally, the same principles and methods may be applied to the construction of what may becalled bevel-face gearing, as shown in Fig. 2149. In this case the…
