A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 330

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 330 — rodpasses to the cylinder, which is not shown in the figure;A B is the connecting rod, and B C the crank, by means ofwhich the shaft C and fl3^-wheel R R are made to revolve.Upon this shaft are two eccentrics E and E,, of which thefirst also moves the connecting rod P of the feed pump, 462.] THE… … which turns out O and carries the counterpoise Q. Bymeans of the handle O H, the link may be raised or low-ered at will, and so placed that the end K of the valve rodmay have any desired position between the ends G and C,.In Fig. 739 we have the valve gear proper, half in ele-vation and half in…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
