A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 353
340 HEAT, STEAM, AND STEAM ENGINES. [§ 471 opened, and the steam would enter freely if the aperture awere not closed by the expansion slide. The steam, there-fore, in this position is cut off and expansion commences. … In IV. both slides have moved up so that a remains closed,and in V. the slide has moved up still further, but the ex-pansion slide has moved down. The aperture a is, there-fore, again open, but the steam is still cut off and the slidehas again its central position. The piston is now at thebottom of…
Mechanics, Applied · Mechanical engineering
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
