A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 354

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 354 — HM encloses a cone R furnishedwith two ribs or flanges, and made to revolve by the spin-dle C G. The spring F shoves the ring in the direction MH,and thus closes a, while the cone R, by means of its ribs rand Tj, moves the ring in the direction HM, and thus drawsthe plug K out of the aperture a. In… … and rp the steam will be admitted twice, or once for eachstroke of the piston. If R is raised, the rib where ittouches the ring has a less elevation, and the time of open-ing of a will be less, and if R is lowered, r and r,, wherethey touch the ring, project out farther, and hence a Avillbe open a…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
