A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 438
0. (A convenient method of effectingthis division is shown in the figure. Bisect the radius D 7in 6, and drawthe straight line C G. From G as a centre describe the arc Z>//, and from Cas a centre the arc HI, thus determining the length of the arc CI, which isone tenth of the circumference).… … nearer extremit}, is equal to the length of the connecting-rod. Then fromeach division of the circumference as a centre, with a radius equal to tl:elength of the cor.necting-rod, describe an arc cutting the line that representsthe stroke, thus determining the piston positions corresponding to the…
Mechanics, Applied · Mechanical engineering
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
