A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc.: and for the self-instruction of inventors, artisans, etc. ... In five divisions .. (1868)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley & son · leaf 120

An illustration from A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc.: and for the self-instruction of inventors, artisans, etc. ... In five divisions .., 1868, leaf 120
r to it, and meeting the circleat cT. In Fig. 112, make Cc=Cc, and make c(^ equal to ccV andparallel to CD, then will d be the isometrical position of thepoint d. 222. Prob. 10. To maJce an approximate construction of the iso-metrical drawing of a circle. PI. X., Fig. 113. By trial we shall…

Geometrical drawing · Mechanical drawing
