A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc.: and for the self-instruction of inventors, artisans, etc. ... In five divisions .. (1868)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley & son · leaf 158

An illustration from A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc.: and for the self-instruction of inventors, artisans, etc. ... In five divisions .., 1868, leaf 158
crewholes, L. k. In di-awing the shelf, K, and flange W, the intersection of thecentre lines BK and mm, is the centre for the curves which inter-sect the centre line AK; the corners, 1 1, of the nuts, v,v, are thecentres for the curves that cross the centre line, vv; and theremaining outlines of…

Geometrical drawing · Mechanical drawing
