Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 252
150 WOODED STRUCTURES. in which burnt sienna prevails, in the parts above the water,and ink, in the muddy parts below the water, and then add, ornot, the pen strokes shown in the plate, to represent sand,gravel, &c. k. Place heavy lines on the right-hand and lower edges of allsurfaces, except…
Geometrical drawing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
