A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc. : and for the self-instruction of inventors,artizans, etc. ... In five divisions .. (1867)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 84
, entersit, is a cylindrical projection or neck, n, having at its outer enda flange, ff through which two or more bolts pass. At its innerend, at p, this neck fits the piston rod quite close for a short space.The internal diameter of the remaining portion of the neck is suffi-cient to receive a…
Geometrical drawing · Mechanical drawing
