Johnston, Philip Devereux, 1855- · New York, D. Williams Company · leaf 112
io8 A MANUAL OF MECHANICAL DRAWING. Plate 35. To Develop the Surface of a Square Prismwith One of Its Corners Cut by a Plane at 45°.Begin by laying out adjacent rectangles to repre-sent the sides 1-2-3-4, adjoining a square representingthe bottom and another the top. In the plan is shownthe cutting…
Mechanical drawing
