Johnston, Philip Devereux, 1855- · New York, D. Williams Company · leaf 46
by measuring oif the length of aside on the projected lines, and draw lines 6 and i,thus giving view of sides 2 and 3. In the foregoing figures or views of the cube all thesides are brought into view except side 6. The figurebeing a cube, this side would be exactly the same asside I, but should… … 6 1 5 ^ i K
Mechanical drawing
