14 MANUAL TRAINING FOR THE RURAL SCHOOLS 15 BENCH HOOK Material Required Lumber: 1 piece white or yellowpine, tIx5%x10% inches.1 piece white or yellowpine, tIxI78x11 inches.(Cypress or Oregon p.nemay be substituted forwhite or yellow pine.) Hardware: 6 flat head bright woodscrews 1% inch. No. 8. … Fig. 12. Setting a Plane. Directions 1—Reduce all pieces to finished dimen-sions. 2—Draw a center line lengthwise ofbig piece. 3—Locate a point on line just draAvn2^4 inches from one end and bore %inch hole. 4—Locate points on each of the smallpieces for screws. 5—Bore holes for screws with 5^…
