Manual training for the rural schools; a group of farm and farm home woodworking problems (1916)
Roehl, Louis M. (Louis Michael), 1881- · Milwaukee, Wis., Bruce Pub. Co · leaf 14
12 MANUAL TRAINING FOR THE RURAL SCHOOLS 13 BENCH HOOK Material Required Lumber: 1 piece white or yellow pine,iix5^x103^ inches. 1 piece white or yellow pinetlxljgxll inches.(Cypress or Oregon pine maybe substituted for white or yel-low pine.) Hardware: 6 flat head bright wood screws134 inch, No. 8. … Fig. 12. Setting a Plane. Directions 1—Reduce all pieces to fini.^hed dimen.sions. 2—Draw a center line lengthwise of big piece. 3—Locate a point on line just drawn 2J|inches from one end and bore % inch hole. 4—Locate points on each of the small piecesfor screws. •^—Bore holes for screws with -^…
Woodwork (Manual training)
