Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 123
the third plan of the fabric structure {c - d ofFig. 154). Diagram 6 in Fig. 155 shows the plan for thecomplete threading of the single cloth trimmings, thuswoven by the three-ply plan. Diagram 7 in Fig. 155 shows the threading of thereed for the trimming thus woven by the three-plyplan. Diagram 8… … For the interlacing of the centre-threads we findused (intermixed) double taffeta and warp rib weave. Since the ribbon is short on one side, becominglonger towards the other, the warp-threads must onaccount of their varying length be bunched in theshape of stripes into one warp. Diagram 156^ shows…
Weaving · Textile fabrics
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
