Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 138
interlacing of warp and filling in thefabric structure. 2 Systems Warp, 1 System Filling. Fig. 164 shows us a sketch for a single shuttleribbon in which the figure is to be produced by meansof an extra warp, i. e., 2 systems of warp and 1 systemof filling are to be used in the cox.struction of… … Fi^jee For this reason, when calculating as to point paperto use, since only the figure warp-threads and thepicks come into consideration, the proportion of thetexture to be considered is 25 : 25, or point paper 6 :6, 8 : 8, or 12 : 12 may be used. The lower portion of the sketch Fig. 164 is…
Weaving · Textile fabrics
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
