Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 185

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 185
s are employed, according to the widthof the loom. The upper part of these lay swords haveupon their upper ends, at their front sides, extensionsor brackets 1, forming surfaces to receive an angleiron bar 2, of angle shape in cross section ofiron or steel, which forms the lav beam of the loom.This… … angle iron bar 2 extends the full width of the loom,and forms the lay beam, taking the place of the ordi-narily used wooden beam. Looms and Devices. 173 Extending along the front side of the vertical por-tion of the angle iron bar 2 is a bar 6, adjustably con-nected to the former by screws 7,…

Weaving · Textile fabrics
