Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 198

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 198
loom frame are therack bar actuating* means, comprising the rolls 9 ec-centrically mounted upon a shaft 10 connected to amoving part of the loom for back and forth rotarymovement. Connected with each of the rolls 9 areflexible straps 11, one of which passes directly aroundthe roll 4 at the same… … means and from thence it passes lengthwise of thebatten about the roller 4 at the opposite end of theloom and is secured to the adjacent end of the rackbar 3. Since the rack bar actuating means 9 is operatedfirst in one and then in the opposite direction it willimpart to the rack bar 3, through the…

Weaving · Textile fabrics
