Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 209

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 209
which is attached to hub H, and the otherto the pawl. The inner ends of said pawls a areprovided with extensions to engage with the hub Hand form a stop, so as to prevent the pawls frombeing drawn over too far by the spring c. 196 Manufacture of Narrow Woven Fabrics. Combined with each take-up… … In Fig. 244 the positions of said projections on thedetachable hand wheel are shown by dotted linesagainst the pawl pivot levers e. The pawls a, being normally in contact with theinternal corrugated surfaces of the take-up pulleys,the same are thereby normally held from turning inthe direction…

Weaving · Textile fabrics
