Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 211

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 211
h the arm and securing the studthereto. 10 is a pressure roller, provided to press thewoven fabric (see dot and dash line) against the sandroller 1. This pressure roller 10 is carried by aspring-support comprising two elastic wires 11, eachwire consisting of a substantially straight portion hav-ing… … Fig^24 7 the hook 15. The studs of the pair of brackets 4project outwardly and receive on them the loops ofthe wires, the hooks of the latter being engagedaround the shaft 3. By changing the position of the pair of brackets 4on its shaft 3 (after again tightening set screw 6)either more or less…

Weaving · Textile fabrics

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
