F SECTION FRAME 40 power with an average air pressure in the fire rooms of not more than 2 inches of water. There are four funnels, which measure about 100 feet above the base line. Sixty-six tons of fresh water will be carried on trial in the double bottom or in reserve tanks. The weight of all… … at both ends, leaving the working bores of such length that the piston rings will over-ride 1-4 inch at the top and 1-8 inch at the bottom. The linear clearances of the various cylinders between pistons and cylinder heads will be 3-8 inch at the top and 5-8 inch at the bottom. The high-pressure…
