Marine engineering (1920)

New York : Simmons-Boardman Pub. Co. · leaf 37

An illustration from Marine engineering, 1920, leaf 37
2402/4 b | No.7 Tank No.8 Tank Store x4 “Trunk No.7 Tank Room No.8 Tank Or Tank 90 fathoms 7%-inch Manilla Fig. 3.—Midship Section

Shipbuilding -- Periodicals · Shipbuilding industry -- Periodicals

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
