Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)

Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 104

An illustration from Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines, 1910, leaf 104 — M. E. P. I. H. P. H = 126.15 H = 2,707.4 M = 41.55 M = 2,565.3 L = 13.50 L = 2,799.1 Total, 8,071.8 Steam 225. M. P. Rec 62. L. P. Rec 11.25 Vacuum 24. R. P. M 77. Piston Speed 808.5 Cut off: H. P. = .71, M. P. = .732, L. P. = Full 100 MARINE INDICATING Series 4
