An illustration from Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines, 1910, leaf 14 — ■•THOMPSl FAT0AUO3lj … Fig. 3 Fig. 6 shows a section through the paper drum of an instrumentfitted with detent motion. 12 MARINE INDICATING • Leading Pulley The leading pulley shown in Fig. 4 consists of a wheel which iscarried on an adjustable bearing. This bearing as shown is carried by astand which is cast with a…
